electropositive water filter cartridge Ultra Filtration

Unique water filtration technology

Using unique, Disruptor™ filtration technology, Ultra Disruptor removes more impurities than any other water filter, including chlorine and harmful bacteria, cysts and viruses with exceptional high flow rates with no rejected water waste.

Electro adsorption enables the removal of a wide range of contaminants. It also means the water filter media can have larger pores, allowing much faster water flow. Ultra Disruptor electro adsorption water filters remove viruses and pathogens (including Legionella), cellular debris, trace pharmaceuticals, chlorine and particulates. Ultra Disruptor technology improves the safety and taste of drinking water.

ULTRA-Disruptor with a pre-sediment wrap and powdered activated carbon (PAC) and silver pleated 0.02-micron* filter cartridge

The Ultra Disruptor Submicron Depth Filter, which is manufactured using a proprietary, patented, electro adsorptive media technology, capable of removing submicron pathogens and inorganic contaminants through electro-adhesion and ion exchange. This technology makes it possible for a nonwoven media to produce filtration efficiency comparable to ultra-membrane filtration but at very low-pressure drop, with high flow rates and high loading capacity working equally well in fresh, brackish or salt waters.

This media has been specifically engineered to have an average pore size of 2 microns and a mean flow pore of 0.7 microns. This allows the naturally occurring charge field to affect the total volume of the individual pores, as well as virtually the entire void volume of the filter media itself.

The media in this filter cartridges efficiently retain inorganic and organic particulates, cell debris, endotoxins, virus, proteins, many colloids, bacteria and inorganic submicron particulates. Contaminants are removed by being exposed to a tortuous path through the media, depth and the powerful electropositive charge.

Applications benefitting from the Ultra Disruptor filtration process:

Residential use where cost-effective systems must be used and the presence of pathogenic-laden water is of ongoing concern

Food and beverage industry for high purity water

Pharmaceutical industry for high purity water

Commercial pre-RO and ultrafiltration treatment to sustain the life of the membranes

Greywater recycling for removal of pathogens

Desalination for pre-filtration

Benefits using the Ultra Disruptor Filter Cartridges versus other media:

Finer particle retention and filtration capacity (2 to 3-micron pore size comparable to a 0.02-micron* size for virus removal)

Higher loading capacity (up to 25 times greater)

Greater efficiency in salt, brackish and freshwater

Wider pH operating window (4-9pH)

Very low-pressure drop (approximately 2 psi)

The ability of using one stand-alone filter system to achieve pathogen, heavy metal, taste and odour, chemical and organics removal or reduction (the carbon and silver version); for a broad range of applications including residential whole-house point-of-entry and point-of-use water filtration.

The media in the Ultra Disruptor filter is NSF/ANSI 42- and 61- certified and UPC-certified by the IAPMO organization (Drinking Water System Components-Health Effects), and USP Class VI testing and endotoxin testing.

The Ultra Disruptor filter reduces or removes the following pathogens:

>99.99% viruses (polio, rotavirus, norovirus, etc.)**

>99.9999% bacteria (e coli, Legionella, Pseudomonas, Legionella, etc.)**

>99.95% cysts (giardia, cryptosporidium, etc.)**

The Ultra Disruptor filter removes or reduces the following heavy metals:

>95% Lead**

>80% Ferrous Iron**

>95% Arsenic V**

>95% Cadmium**

>85% Chromium**

>75% Selenium**

>60% Mercury

The Ultra Disruptor filter removes or reduces the following organic and inorganic chemicals:

Chlorine (carbon version)

Bromine (carbon version)

Iodine (carbon version)

VOCs (volatile organic compounds)

PCBs and BPA

Residual pharmaceuticals and drugs

Endocrine Disruptors

Hormones

Microplastics

Biofouling precursors: organic acids, proteins, polysaccharides

* Finer particle retention and filtration capacity (2 to 3-micron pore size comparable to a 0.02-micron size for virus removal)

**Tested by a certified laboratory. (testing was done at 6.5pH)
